JEE PYQ: Motion In One Dimension Question 17

Question 17 - 2020 (04 Sep Shift 2)

The speed verses time graph for a particle is shown in the figure. The distance travelled (in m) by the particle during the time interval $t = 0$ to $t = 5$ s will be __________.

Speed (ms$^{-1}$) vs time (s) graph — linear increase from 0 to about 8 m/s over 0 to 5 s, with data points at integer times

Show Answer

Answer: 20
